Application:

The range of angle brackets are designed to create a simple and strong connection between two timbers where they meet or cross at right angles.

Installation:

  • Select the correct angle bracket.
  • Align the two timbers at right angles.
  • Fix both ends of the angle bracket using wood screws.

Variations:

Bracket Type                          Dimensions (mm)                   Material Thickness

Narrow Square
​25 x 25 x 17

40 x 40 x 17

50 x 50 x 17

75 x 75 x 17



Wide Square
​30 x 30 x 30                                         2mm

40 x 40 x 40                                         2mm

50 x 50 x 50                                         2mm

60 x 60 x 60                                         2mm



Splice Plate
​300 x 80 x 20                                       2mm

400 x 80 x 20                                       2mm

500 x 80 x 20                                       2mm



Material:

All of the angle bracket range are manufactured from pre-galvanised mild steel.
